Product type
Feed-through terminal block
Area of application
Machine building
Plant engineering
Process industry
Railway industry
Maximum power dissipation for nominal condition
Number of connections per level
Internal cylindrical gage
Connection in acc. with standard
Conductor cross-section rigid
Cross section AWG
24 ... 8 (converted acc. to IEC)
Conductor cross-section flexible
Conductor cross-section, flexible [AWG]
24 ... 8 (converted acc. to IEC)
Conductor cross-section flexible ultrasound-compressed
Conductor cross-section, flexible [AWG] ultrasound-compressed
22 ... 8 (converted acc. to IEC)
Conductor cross-section flexible (ferrule without plastic sleeve)
Flexible conductor cross-section (ferrule with plastic sleeve)
2 conductors with same cross section, rigid
2 conductors with same cross section, flexible
2 conductors with same cross section, flexible, with ferrule without plastic sleeve
2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve
Maximum load current
57 A (with 10 mm² conductor cross-section)
Note
Note: Product releases, connection cross sections and notes on connecting aluminum cables can be found in the download area.
Flammability rating according to UL 94
Insulating material group
Ambient temperature (operation)
-60 °C ... 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.)
Ambient temperature (storage/transport)
-25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Ambient temperature (assembly)
Ambient temperature (actuation)
