Notes on operation
Do not use to separate SELV/PELV circuits from other circuits, because safe isolation is not guaranteed. (applies to the optocoupler variants)
The outputs are not suitable for switching different outer conductors.
The system installer must ensure the touch protection of the product (at voltages > 25 V AC/60 V DC). The product is a built-in device without protection against direct contact.
Typical input current at UN
Input power dissipation for UN
Mechanical service life
approx. 5x 10<sup>7</sup> cycles
Date of last data management
Maximum power dissipation for nominal condition
Test voltage (Winding/contact)
5 kV<sub>rms</sub> (50 Hz, 1 min., winding/contact)
Test voltage (Changeover contact/changeover contact)
3 kV<sub>rms</sub> (50 Hz, 1 min., changeover contact/changeover contact)
Test voltage (open contact)
1 kV<sub>rms</sub> (50 Hz, 1 min., open contact)
Nominal input voltage U<sub>N</sub>
Typical input current at U<sub>N</sub>
Input power dissipation for U<sub>N</sub>
Typical release time range
Maximum switching voltage
Minimum switching voltage
Limiting continuous current
Maximum inrush current
16 A (20 ms, N/O contacts)
Interrupting rating (ohmic load) max.
192 W (24 V DC)
2000 VA (250 V AC)
240 W (30 V DC)
Degree of protection (Relay)
Degree of protection (Installation location)
IP54 (Installation location)
Ambient temperature (operation)
Ambient temperature (storage/transport)
