Inrush current integral (I2t)
Supply system configuration
Star network (TN, TT, IT (PE))
Input voltage range
100 V AC ... 240 V AC -15 % ... +10 %
110 V DC ... 250 V DC -20 % ... +10 %
Nominal output current (IN)
Typical national grid voltage
Voltage type of supply voltage
Inrush current integral (I<sup>2</sup>t)
Frequency range (f<sub>N</sub>)
Mains buffering time
typ. 18 ms (120 V AC)
typ. 80 ms (230 V AC)
Current consumption
0.07 A (250 V DC)
0.14 A (240 V AC)
0.17 A (110 V DC)
0.3 A (100 V AC)
Device mains fuse
1.25 A internal (device protection), slow-blow
Recommended breaker for input protection
6 A ... 16 A (Characteristics B, C, D, K)
Efficiency
> 81.5 % (120 V AC)
> 82 % (230 V AC)
Nominal output current (I<sub>N</sub>)
Derating
> 50 °C ... 70 °C (2 % / K)
Output power (P<sub>N</sub>)
Connection in parallel
yes, for increasing power and redundancy with diode
Connection in series
yes, for increased output voltage
Feedback voltage resistance
Protection against overvoltage at the output (OVP)
Control deviation
< 0.1 % (change in input voltage ±10 %)
< 1.5 % (Static load change 10 % ... 90 %)
< 5 % (Dynamic load change 10 % ... 90 %, (10 Hz))
Rise time
typ. 100 ms (U<sub>Out</sub> = 10 % ... 90 %)
Minimum no-load power dissipation
Maximum no-load power dissipation
Minimum nominal load power dissipation
Power loss nominal load max.
Integrated fuse protection
Position marking
1.1, 1.2 (L), 1.3, 1.4 (N)
2.1 (USB-A)
rigid
0.2 mm² ... 2.5 mm²
1 mm² (recommended)
flexible
0.2 mm² ... 2.5 mm²
1 mm² (recommended)
flexible with ferrule without plastic sleeve
0.5 mm² ... 1.5 mm²
1 mm² (recommended)
flexible with ferrule with plastic sleeve
0.2 mm² ... 1 mm²
1 mm² (recommended)
Stripping length
10 mm (rigid/flexible/ferrule without plastic sleeve)
13 mm (Ferrule with plastic sleeve)
Signal threshold
< 0.9 x U<sub>N </sub>(U<sub>N</sub> = 5 V DC) (LED off)
> 0.9 x U<sub>N </sub>(U<sub>N</sub> = 5 V DC) (LED lights up green)
Insulation voltage input/output
3.75 kV AC (routine test)
4 kV AC (type test)
