SAC-5P-M12MS/0,3-PVC/M12FS VA Sensor/actuator cable

Manufactured by

Brand PHOENIX CONTACT

Sensor/actuator cable, Universal, 5-position, PVC, black RAL 9005, Plug straight, coding: A, on Socket straight, coding: A, cable length: 0.3 m

4067923456495

only

available

100+

99999

pcs.

(2026-10-11)

Supply from Phoenix Contact’s warehouse

Product recommended retail price (RRP) is

0⁰⁰€

22²⁰€ 0 € pcs.

All prices without tax

All prices with tax

inquiry

only

available

100+

inquiry

2026-10-11

pcs.

Properties

Description

Dimensions

Files

Codes

Nominal voltage UN

48 V AC

60 V DC

Product type

Sensor/actuator cable

Nominal current IN

4 A

Number of positions

Shielded

Overvoltage category

Degree of pollution

Nominal voltage U<sub>N</sub>

48 V AC

60 V DC

Nominal current I<sub>N</sub>

4 A

Tightening torque

0.4 Nm

Type

Socket straight

Coding type

Cable length

0.3 m

Cable weight

51 kg/km

UL AWM Style

2464 / 1729 (80°C/300 V)

Cable type

PVC black [PVC]

Conductor structure signal line

19x 0.15 mm

AWG signal line

Conductor cross-section

5x 0.34 mm² (Signal line)

Wire diameter incl. insulation

1.26 mm ±0.05 mm

External cable diameter

5.00 mm ±0.15 mm

Outer sheath, material

PVC

External sheath, color

black RAL 9005

Conductor material

Bare Cu litz wires

Material wire insulation

PVC

Single wire, color

brown, white, blue, black, green-yellow

Thickness, insulation

≥ 0.23 mm (Core insulation)

Thickness, outer sheath

≥ 0.76 mm

Overall twist

5 wires around filler to the core

Max. conductor resistance

max. 57 Ω/km (at 20 °C)

Insulation resistance

≥ 200 MΩ*km (at 20 °C)

Nominal voltage, cable

≤ 300 V

Test voltage

≥ 3000 V

Minimum bending radius, fixed installation

5 x D

Minimum bending radius, flexible installation

10 x D

Smallest bending radius, fixed installation

25 mm

Smallest bending radius, movable installation

50 mm

Flame resistance

UL VW-1

Resistance to oil

in accordance with DIN EN 60811-2-1

Ambient temperature (operation)

-10 °C ... 80 °C (Cable, flexible installation)

-25 °C ... 80 °C (cable, fixed installation)

Degree of protection

IP65

IP67

IP68

Length

Width

Height

Weight Net

Weight

Package

Volume

m³

No files found

ECLASS-13.0

27060311

ECLASS-15.0

27060311

ETIM 10.0

EC001855

GTIN

4067923456495
