Maximum continuous operating voltage UC
Short-circuit current rating ISCCR
Type
Base element, DIN rail mounting
Surge protection fault message
Remote indication contact
Nominal frequency f<sub>N</sub>
Connection name
Remote fault indicator contact
Operating voltage
125 V AC
30 V DC
5 V AC ... 250 V AC
Operating current
1 A DC
5 mA AC ... 1.5 A AC
Connection method
Fork-type cable lug
Plug-in/screw connection via COMBICON
Screw connection
Tightening torque
0.25 Nm
3 Nm (1.5 mm² ... 16 mm²)
30 lb<sub>f</sub>-in.
4.5 Nm (25 mm² ... 35 mm²)
Conductor cross-section flexible
0.14 mm² ... 1.5 mm²
1.5 mm² ... 16 mm²
1.5 mm² ... 25 mm²
Conductor cross-section rigid
0.14 mm² ... 1.5 mm²
1.5 mm² ... 35 mm²
Conductor cross-section AWG
14 ... 2
15 ... 2
28 ... 16
Depth
51.5 mm (incl. DIN rail 7.5 mm)
Flammability rating according to UL 94
Maximum continuous operating voltage U<sub>C</sub>
Rated load current I<sub>L</sub>
Short-circuit current rating I<sub>SCCR</sub>
Max. backup fuse with V-type through wiring
Max. backup fuse with branch wiring
Degree of protection
IP20 (only when all terminal points are used)
Ambient temperature (operation)
Ambient temperature (storage/transport)
Permissible humidity (operation)
Shock (operation)
25g (Half-sine / 11 ms / 3x ±X, ±Y, ±Z)
Vibration (operation)
5g (10 ... 500 Hz / 2.5 h / X, Y, Z)
