Connection method
Inline data jumper
Spring-cage connection
Required configuration data
Output voltage
24 V DC (U<sub>S</sub> - 1 V)
Maximum output current per channel
Maximum output current per module
Nominal output voltage
24 V DC (voltage difference at I<sub>nom</sub> ≤ 1 V)
Behavior with inductive overload
Behavior at voltage switch-off
The output follows the power supply without delay
Scope of supply
including Inline connectors and marking fields
Operating mode
Process data mode with one byte
Overvoltage category
II (IEC 60664-1, EN 60664-1)
Pollution degree
2 (IEC 60664-1, EN 60664-1)
Maximum power dissipation for nominal condition
Supply voltage
24 V DC (via voltage jumper)
7.5 V DC (via voltage jumper)
Supply voltage range
19.2 V DC ... 30 V DC (including all tolerances, including ripple)
Test voltage: 7.5 V supply (bus logics)/24 V supply (I/O)
Test voltage: 7.5 V supply (bus logic)/functional ground
Test voltage: 24 V supply (I/O) / functional ground
Conductor cross-section, rigid
